Peb Direct Drive Angle Grinder nta lub siab tshaj plaws gearless brushless lub cev muaj zog, tshem tawm cov iav sib dhos kom ua kom lub zog ua haujlwm zoo, txo qis kev txij nkawm, thiab xa cov torque zoo ib yam rau kev xav tau kev sib tsoo thiab hlau fabrication.
Technical Specifications
|
Technical Parameter |
Specification Range / Standard |
|
Tsav Architecture |
Brushless Direct Drive (Gearless Fais fab Hloov) |
|
Tau tshaj Disc Diameter |
100mm (4 ") / 115mm (4-1 / 2") / 125mm (5") / 180mm (7") / 230mm (9") |
|
Rated Fais fab Input |
1000W - 2200W sib npaug kev ua haujlwm |
|
Tsis muaj -Load Speed Range |
4,500 RPM - 11,000 RPM (Variable ceev xaiv muaj) |
|
Hom Tsav |
High -Efficiency Permanent Magnet Brushless Tsav (BLDC) |
|
Spindle Xov Standard |
M14 / 5/8 "-11 (Customizable ib lub lag luam hauv cheeb tsam) |
|
Qhov hnyav |
1.8 kg - 3.5 kg (nyob ntawm kev teeb tsa, tsis suav nrog roj teeb / cable) |
|
Kev xaiv qhov chaw fais fab |
High-voltage Cordless Li-ion (piv txwv li, 36V / 40V platform) lossis Hnyav-Lub luag haujlwm Corded AC |
Cov yam ntxwv tseem ceeb
Gearless Direct Fais fab Hloov:Tshem tawm cov tsoos bevel iav rau kev sib txuas ncaj nraim, tshem tawm kev sib txhuam thiab lub zog poob kom ua kom lub zog ua haujlwm zoo.
Active Electronic Braking:Ntsig lub rotating disc nyob rau hauv qis dua 2 vib nas this thaum tso tawm, txo qis kev ua hauj lwm txaus ntshai nyob rau hauv ceev -paced ib puag ncig.
Anti-Kickback & Overload Protection:Tsis siv neeg txiav fais fab thaum lub sij hawm tam sim no disc khi los yog hnyav overloads, tiv thaiv ob tus neeg teb xov tooj thiab lub cev muaj zog architecture.
G2.5 Precision Dynamic Ntsuas:Precision-sib npaug sab hauv rotors txo qis kev ua haujlwm kev co, txo tes-arm vibration syndrome (HAVS) kev pheej hmoo thaum ntau- ua haujlwm ua haujlwm.
OEM/ODM
Custom Branding & Aesthetics:Kev them nyiaj yug rau tus kheej daim ntawv lo laser engraving, txhob lo lo ntxhuav - tshuaj ntsuam xyuas, thiab Pantone -xim vaj tse xim kom haum raws li koj lub tuam txhab hom cim.
Ntim Solutions:ISTA- ntawv pov thawj poob- tau kuaj cov ntim khoom xa tawm, suav nrog kev cai tshuab- pwm nqa nqa (BMC) nrog cov khoom siv tshwj xeeb.
Supply Chain Reliability:Cov ntaub ntawv txhua hli muaj peev xwm ntau tshaj 20,000 units, txhawb nqa los ntawm kev ruaj khov 30-35 hnub ua haujlwm rau cov qauv xaj rov qab.
Cov ntawv thov kev lag luam
Heavy Hlau Fabrication:Qhov zoo tshaj plaws rau kev txuas ntxiv, siab - siv txiav cov qauv hlau tuab, carbon steel daim hlau, thiab kev npaj cov pob qij txha hnyav.
Foundry & Casting Clean-up:Tshem tawm cov tawv nqaij tawv tawv, flash, thiab cov kab sib cais los ntawm cov hlau thiab hlau castings hauv siab - plua plav, ib puag ncig nruj.
Pipeline Kev Tsim Kho & Kho:Muab kev cia siab, tsis tu ncua -kev ua haujlwm nrawm rau qhov xav tau ntawm qhov chaw ua haujlwm, cov yeeb nkab beveling, thiab hnyav saum npoo.
Shipbuilding & Offshore:Tsim los txhawm rau tshem tawm cov khoom hnyav, xeb stripping, thiab vuam sib xyaw ntawm loj - nplai marine qauv.
Quality Assurance
European Market:CE- tau ntawv pov thawj (Machinery Directive 2006/42/EC), ua tau raws li RoHS thiab REACH txwv cov khoom siv.
North American Alignment:Cov khoom siv hluav taws xob thiab thermal tseem ceeb los ntawm UL/ETL- lees paub cov saw hlau.
Cov ntaub ntawv txhawb nqa:Cov ntaub ntawv tshaj tawm kev xeem, suav nrog cov suab nrov emission (EN 60745) thiab cov ntaub ntawv vibration magnitude, tau npaj txhij rau kev kuaj xyuas kev ua raws cai.
Ntim & Logistics
Kev tiv thaiv kev thauj mus los:Engineered nrog kev cai - molded pulp los yog siab - ntom EPE npuas sab hauv kom ruaj ntseg ncaj nraim - tsav tsheb sib dhos thaum lub sij hawm xa khoom thoob ntiaj teb.
Cov ntaub ntawv logistics:
- Unit Nyhav (Liab Tool): 1.25 kg (Lighter vim gearbox tshem tawm)
- Master Carton (10 units): 42 x 28 x 22 cm|Kwv yees . 14.5 k
Ua tiav Flexibility:Txhawb nqa palletized hiav txwv freight thawv loading thiab ncaj qha dropshipping qauv.
Khoom plig & Kev lees paub
Cov lus nug nquag
Q: Dab tsi yog qhov txiaj ntsig tseem ceeb ntawm kev tsav ncaj qha dhau lub iav- tsav cov qauv?
A: Kev tsav ncaj qha tshem tawm cov theem bevel iav, uas yog qhov tseem ceeb ntawm kev siv tshuab, tsim hluav taws xob, thiab hluav taws xob poob. Qhov no ua rau muaj kev ua haujlwm siab dua thiab kev saib xyuas qis dua.
Q: Lub tsev puas yuav tsum tau lubrication raws sij hawm?
A: Tsis yog. Qhov tsis muaj lub thawv iav txhais tau tias tsis tas yuav tsum muaj lubrication sab hauv lossis hloov roj.
Q: Cov neeg ua haujlwm yuav tsum xav txog qib twg?
A: Peb cov rotors yog dynamically sib npaug rau G2.5 cov qauv, ua rau muaj kev vibration theem qis dua qhov pib rau tus qauv EN 60745 kev lag luam.
Q: Cov grinders no puas haum rau kev siv hnyav hnyav ntxiv?
A: Yog. Lub tshuab ua kom zoo thermal tswj thiab tsis siv lub cev muaj zog yog tsim tshwj xeeb rau kev ua haujlwm siab - xws li steel fabrication thiab shipbuilding.
Q: Cov yam ntxwv kev nyab xeeb dab tsi suav nrog?
A: Cov chav nyob tau nruab nrog lub tshuab hluav taws xob ua haujlwm, tiv thaiv -kickback sensor, thiab rov pib tiv thaiv kev tiv thaiv kom tsis txhob muaj kev sib tsoo tom qab hluav taws xob txiav.
Q: Koj puas tuaj yeem pab txhawb kev tsim khoom lag luam lossis cov qauv xim?
A: Yog lawm, peb muab tag nrho OEM / ODM cov kev pabcuam, suav nrog kev sib koom ua ke logo, Pantone- tshwj xeeb casing, thiab lub thawv ntim khoom siv rau cov neeg koom tes lag luam wholesale.
Q: Lub sij hawm ua tus txheej txheem rau kev txiav txim ntau yog dab tsi?
A: Lub sij hawm ua tus qauv yog 30-35 hnub los ntawm kev txiav txim pom zoo. Kev nyab xeeb cov khoom yog khaws cia rau kev txiav txim rov qab kom ua tiav sai dua.
Q: Koj puas muab cov khoom seem txhawb nqa?
A: Peb muab cov npe khoom seem rau txhua tus qauv thiab tswj kom muaj cov khoom tseem ceeb rau yam tsawg kawg ntawm 5 xyoos tom qab cov khoom tsim khoom tiav.
Cim npe nrov: Tuam Tshoj direct tsav lub kaum sab xis grinder manufacturers, lwm tus neeg, Hoobkas
